OptiX OSN 7500
Technical Manual - System Description 3 Hardware
Huawei Technologies Proprietary
3-13
3 Hardware
This chapter describes the hardware structure of the OptiX OSN 7500, including the
outer view and parameters of the cabinet, and structure of the subrack. It covers:

Outer view and parameters of the cabinet

Subrack structure
3.1 Cabinet
The OptiX OSN 7500 can be installed in the ETSI cabinet. Table 3-1 shows the
technical parameters of the ETSI cabinet. Figure 3-1 shows the outer view of the ETSI
cabinet.
Table 3-1 Technical parameters of the ETSI cabinett
Size (mm) Weight (kg) Number of configured subracks
600 (W) x 300 (D) x 2000 (H) 60 1
600 (W) x 600 (D) x 2000 (H) 64 1
600 (W) x 300 (D) x 2200 (H) 70.4 2
600 (W) x 600 (D) x 2200 (H) 101 2
600 (W) x 300 (D) x 2600 (H) 80 2
600 (W) x 600 (D) x 2600 (H) 112.3 2
