OptiX OSN 7500
Technical Manual - System Description 4 Boards
Huawei Technologies Proprietary
4-9
Boa rd Full name Available slot Interface
type
Used with
D12B 32 x E1/T1 electrical
interface board
slot 19–slot 22, slot 35–slot 38 DB44 PQ1, PQM
4.2.3 Data service Interface Unit
Table 4-8 shows the data service processing boards and their available slots, and
Table 4-9 shows the data service interface boards and their available slots.
Table 4-8 Data service processing boards and their available slots
Board Full name Slot available Outlet mode Interface type Connector
EGS2 2-port Gigabit
Ethernet
interface board
slot 1–slot 8,
slot 11–slot 18,
slot 26–slot 31
Led out from
the front panel
1000BASE-SX/LX/ZX LC
EFS0 Fast Ethernet
interface board
with LAN switch
slot 2–slot 3,
slot 17–slot 18
Led out from
the interface
board
10/100BASE-TX RJ-45
EFS4 4-port fast
Ethernet
interface board
with LAN switch
slot 1–slot 8,
slot 11–slot 18,
slot 26–slot 31
Led out from
the front panel
10/100BASE-TX RJ-45
EGT2 2-port Gigabit
Ethernet
transparent
transmission
board
slot 1–slot 8,
slot 11–slot 18,
slot 26–slot 31
Led out from
the front panel
1000BASE-SX/LX/ZX LC
EFT8 8-port fast
Ethernet
transparent
transmission
board
slot 1–slot 8, slot
11–slot 18, slot
26–slot 31
Led out from
the front panel
10/100BASE-TX RJ-45
EMR0 12 FE + 1 GE
Ethernet ring
network board
slot 2–slot 3,
slot 17–slot 18
Led out from
the front panel
or the interface
board
10/100BASE-TX,
1000BASE-SX/LX/ZX
RJ-45, LC
