Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
17
Pin
Signal
Function
6
-
Reserved
7
-
Reserved
8
GND
GND
9
N.C
Not defined
Table 4-5 Pin assignment of the LAMP1/LAMP2 interface
Pin
Signal
Function
1
CRIT_ALMP
Critical alarm signal
positive
2
CRIT_ALMN
Critical alarm signal
negative
3
MAJ_ALMP
Major alarm signal positive
4
RUNP
Power indicating signal
positive
5
RUNN
Power indicating signal
negative
6
MAJ_ALMN
Major alarm signal positive
7
MIN_ALMP
Minor alarm signal positive
8
MIN_ALMN
Minor alarm signal negative
Table 4-6 Pin assignment of the ALMO1/ALMO2 interface
Pin
Signal
Function
1
CRIT_SWITCH_OUTP
Outputs the critical alarm
signal positive
2
CRIT_SWITCH_OUTN
Outputs the critical alarm
signal negative
3
MAJ_SWITCH_OUTP
Outputs the major alarm
signal positive
4
MIN_SWITCH_OUTP
Outputs the minor alarm
signal positive
5
MIN_SWITCH_OUTN
Outputs the minor alarm
signal negative
6
MAJ_SWITCH_OUTN
Outputs the major alarm
signal negative
