Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
66
Unit Name
Typical
Power
Consumptio
n (W)
a
Maximum
Power
Consumptio
n (W)
a
Remarks
EFI, 1 x ATE, and 1 x fan tray
assembly
OADM subrack
449.5
561.5
2 x OAU1, 2 x MR8V, 2 x FIU, 8 x
LSX, 1 x SC2, 1 x XCH, 2 x PIU, 1 x
AUX, 1 x EFI, 1 x ATE, and 1 x fan
tray assembly
221
269.2
1 x M40, 1 x D40, 1 x WSMD9, 1 x
DAS1, 1 x XCH, 2 x PIU, 1 x AUX,
1 x EFI, 1 x ATE, and 1 x fan tray
assembly
OCS subrack
821
1109
2 x UXCM, 4 x NS3, 2 x PIU, 5 x
SLQ64, 4 x SLO16, 1 x SLH41, 1 x
EGSH, 2 x AUX, 1 x EFI, 1 x ATE,
and 1 x fan tray assembly
a: Indicates that the power consumption of the subrack and cabinet is the value in a certain
configuration. The value is for reference only. The actual power consumed by the chassis
and cabinet is a calculation based on the power consumption of each module. The
maximum power consumption is the power consumed by the board when it works normally
under the highest ambient temperature.
4.4.7 Mechanical Specifications
Table 4-45 lists the mechanical specifications of the OptiX OSN 8800 T16 subrack.
Table 4-45 Mechanical specifications of the OptiX OSN 8800 T16
Item
Specification
Dimensions
498 mm (W) × 295 mm (D) × 450 mm (H)
(19.6 in. (W) × 11.6 in. (D) × 17.7 in. (H))
Weight (empty subrack
a
)
18 kg (39.6 lb.)
a: An empty subrack means no boards are installed in the board area, and no fan tray
assembly or air filter is installed.
4.5 OptiX OSN 8800 Universal Platform Subrack
The OptiX OSN 8800 universal platform subrack can be installed in an N63B, N66B, or
19-inch cabinet. The subrack has 16 service slots.
