Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
44
Unit Name
Typical Power
Consumption
(W)
a
Maximum
Power
Consumption
(W)
a
Remarks
subrack
x SC2, 1 x SCC, 4 x PIU, 1 x AUX,
1 x EFI1, 1 x EFI2, 1 x ATE, and 2
x fan tray assembly
378.2
811
2 x M40V, 2 x D40, 2 x FIU, 1 x
SC2, 2 x RMU9, 2 x WSM9, 2 x
OAU1, 2 x OBU1, 1 x SCC, 4 x
PIU, 1 x AUX, 1 x EFI1, 1 x EFI2,
1 x ATE, and 2 x fan tray assembly
373.1
306.6
2 x M40, 2 x D40, 2 x WSMD9, 2 x
DAS1, 1 x SCC, 4 x PIU, 1 x AUX,
1 x EFI1, 1 x EFI2, 1 x ATE, and 2
x fan tray assembly
OCS
subrack
(general
subrack)
1282
1755
2 x XCM, 10 x SLQ64, 8 x SLO16,
2 x SLH41, 2 x EGSH, 2 x STG, 1
x STI, 2 x SCC, 4 x PIU, 1 x AUX,
1 x EFI1, 1 x EFI2, 1 x ATE, and 2
x fan tray assembly
OCS
subrack
(enhanced
subrack)
1791
2321
2 x UXCM, 10 x SLQ64, 8 x
SLO16, 2 x SLH41, 2 x EGSH, 2 x
STG, 1 x STI, 2 x SCC, 4 x PIU, 1
x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 2 x fan tray assembly
a: Indicates that the power consumption of the subrack and cabinet is the value in a certain
configuration. The value is for reference only. The actual power consumed by the chassis
and cabinet is a calculation based on the power consumption of each module. The
maximum power consumption is the power consumed by the board when it works normally
under the highest ambient temperature.
4.3.7 Mechanical Specifications
Table 4-27 lists the mechanical specifications of the OptiX OSN 8800 T32 equipment.
Table 4-27 Mechanical specifications of the OptiX OSN 8800 T32
Item
Specification
Dimensions
498 mm (W) × 295 mm (D) × 900 mm (H)
(19.6 in. (W) × 11.6 in. (D) × 35.4 in. (H))
Weight (empty subrack
a
)
35 kg (77.1 lb.)
a: An empty subrack means no boards are installed in the board area, and no fan tray
assembly or air filter is installed.
