Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
58
Pin
Signal
Function
7
SWITCHI_IN8
Alarm input 8
8
GND
Ground
Table 4-37 Pin assignment of the CLK1/CLK2 interface
Pin
Signal
Function
1
RJ0_E1_RX_N
2MHz/2Mbit input negative
2
RJ0_E1_RX_P
2MHz/2Mbit input positive
3
N C
Not connected
4
RJ0_E1_TX_N
2MHz/2Mbit output
negative
5
RJ0_E1_TX_P
2MHz/2Mbit output positive
6
N C
Not connected
7
N C
Not connected
8
N C
Not connected
Table 4-38 Pin assignment of the TOD1/TOD2 interface
Pin
Signal
Function
1
GND
Ground
2
GND
Ground
3
DCLS_IN0_N
1PPS negative
4
GND
Ground
5
GND
Ground
6
DCLS_IN0_P
1PPS positive
7
DCLS_OUT0_N
TOD negative
8
DCLS_OUT0_P
TOD positive
4.4.4 Cross-Connect Capacities
OptiX OSN 8800 T16 subracks can cross-connect ODU0, ODU1, ODU2, ODU2e, ODU3,
ODU4, ODUflex, VC-4, VC-3, VC-12 granularities and packet services at the same time.
Slots IU1-IU8 and IU11-IU18 provide the same cross-connect capacity. As shown in Table
4-39.
