Huawei OptiX OSN 8800 - 4.3.2 Slot Description

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
33
These two types of subracks cannot be exchanged.

Board area: All the boards are installed in this area. 50 slots are available.

Fiber cabling area: Fiber jumpers from the ports on the front panel of each board are
routed to the fiber cabling area before being routed on a side of the open rack.

Fan tray assembly: Fan tray assembly contains three fans that provide ventilation and
heat dissipation for the subrack. The front panel of the fan tray assembly has four
indicators that indicate subrack status.

Air filter: It protects the subrack from dust in the air and requires periodic cleaning.

Fiber spool: Rotable fiber spools are on two sides of the subrack. Extra fibers are coiled
in the fiber spool on the open rack side before being routed to another subrack.

Mounting ears: The mounting ears attach the subrack in the cabinet.
4.3.2 Slot Description
The OptiX OSN 8800 T32 subrack provide 50 slots.
Slots of the OptiX OSN 8800 T32 subrack are shown in Figure 4-12.
