Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
43
Table 4-26 Power consumption of the subrack in typical configuration in an OptiX OSN 8800
T32
Unit Name
Typical Power
Consumption
(W)
a
Maximum
Power
Consumption
(W)
a
Remarks
OTU
subrack 1
1633
2255
32 x LDX, 1 x SCC, 4 x PIU, 1 x
AUX, 1 x EFI1, 1 x EFI2, 1 x ATE,
and 2 x fan tray assembly
OTU
subrack 2
1684
2023
10 x TN17LSC, 2 x SCC, 4 x PIU,
1 x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 2 x fan tray assembly
OTU
subrack 3
1834
2193
10 x TN17LTX, 2 x SCC, 4 x PIU,
1 x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 2 x fan tray assembly
OTU
electrical
cross-connec
t subrack 1
(general
subrack)
1642
2167
2 x XCH, 20 x NQ2, 1 x SCC, 4 x
PIU, 5 x TQX, 5 x TOA, 1 x AUX,
1 x EFI1, 1 x EFI2, 1 x ATE, and 2
x fan tray assembly
OTU
electrical
cross-connec
t subrack 2
(general
subrack)
1670
2183
2 x XCH, 8 x NS3, 2 x SCC, 4 x
PIU, 2 x TQX, 5 x TOA, 2 x STG,
1 x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 2 x fan tray assembly
OTU
electrical
cross-connec
t subrack
(enhanced
subrack)
2371
2820
2 x UXCH, 10 x
TN58NS4(SDFEC2), 2 x TSC, 8 x
TN55TTX, 2 x SCC, 4 x PIU, 1 x
AUX, 1 x EFI1, 1 x EFI2, 1 x ATE,
and 2 x fan tray assembly
OTM
subrack 1
793
1287
1 x M40V, 1 x D40, 1 x OAU1, 1 x
OBU1, 12 x LDX, 1 x SCC, 4 x
PIU, 1 x AUX, 1 x EFI1, 1 x EFI2,
1 x ATE, and 2 x fan tray assembly
OTM
subrack 2
1731
2088
1 x M40V, 1 x D40, 1 x OAU1, 1 x
OBU1, 10 x TN17LSC, 2 x SCC, 4
x PIU, 1 x AUX, 1 x EFI1, 1 x
EFI2, 1 x ATE, and 2 x fan tray
assembly
OLA
subrack
290.3
706
4 x OBU1, 4 x VA1, 1 x SC2, 1 x
SCC, 4 x PIU, 1 x AUX, 1 x EFI1,
1 x EFI2, 1 x ATE, and 2 x fan tray
assembly
OADM
974
1497.2
2 x OAU1, 2 x MR8V, 16 x LDX, 1
