Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
30
Table 4-19 Power consumption of the common units in an OptiX OSN 8800 T64
Unit Name
Typical Power
Consumption
(W)
a
Maximum
Power
Consumption
(W)
a
Remarks
OTU
subrack 1
1805
2828
32 x LDX, 1 x SCC, 8 x PIU, 2 x
AUX, 1 x EFI1, 1 x EFI2, 1 x ATE,
and 4 x fan tray assembly
OTU
subrack 2
3311
3974
20 x TN17LSC, 2 x SCC, 8 x PIU, 2
x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, 4 x fan tray assembly
OTU
subrack 3
3611
4313
20 x TN17LTX, 2 x SCC, 8 x PIU,
2 x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, 4 x fan tray assembly
OTU
electrical
cross-connec
t subrack 1
(general
subrack)
2173
2823
2 x XCT, 2 x SXH, 8 x NS3, 2 x
SCC, 2 x STG, 8 x PIU, 5 x TQX, 5
x TOA, 2 x AUX, 1 x EFI1, 1 x
EFI2, 1 x ATE, and 4 x fan tray
assembly
OTU
electrical
cross-connec
t subrack 2
(general
subrack)
1839
2777
2 x XCT, 2 x SXM, 20 x NQ2, 1 x
SCC, 8 x PIU, 5 x TOA, 5 x TQX, 2
x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 4 x fan tray assembly
OTU
electrical
cross-connec
t subrack
(enhanced
subrack)
4739
5681
2 x UXCT, 2 x USXH, 20 x
TN58NS4(SDFEC2), 10 x TSC, 6 x
TN55TTX, 5 x TN56TOX, 2 x
SCC, 8 x PIU, 2 x AUX, 1 x EFI1, 1
x EFI2, 1 x ATE, and 4 x fan tray
assembly
OTM
subrack 1
964
1860
1 x M40V, 1 x D40, 1 x OAU1, 1 x
OBU1, 12 x LDX, 1 x SCC, 1 x
SC2, 8 x PIU, 2 x AUX, 1 x EFI1, 1
x EFI2, 1 x ATE, and 4 x fan tray
assembly
OTM
subrack 2
3358
4039
1 x M40V, 1 x D40, 1 x OAU1, 1 x
OBU1, 20x TN17LSC, 2 x SCC, 8 x
PIU, 2 x AUX, 1 x EFI1, 1 x EFI2,
1 x ATE, 4 x fan tray assembly
OCS subrack
(general
subrack)
1748
2636
2 x SXM, 20 x SLD64, 8 x SLO16,
4 x SLQ16, 4 x SLH41, 4 x EGSH,
2 x STG, 1 x STI, 2 x SCC, 8 x PIU,
2 x AUX, 1 x EFI1, 1 x EFI2, 1 x
ATE, and 4 x fan tray assembly
OCS subrack
2135
3076
2 x USXH, 20 x SLD64, 8 x
