Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
Hardware Updates in V100R008C00
Hardware Update
Reason for the Update
Added the OptiX OSN 8800
universal platform subrack.
The OptiX OSN 8800 universal platform subrack can be
installed in an N63B, N66B, or 19-inch cabinet. The
subrack has 16 service slots and its rated current is 60 A.
Added the application of the
TN12LSX board in the OptiX
OSN 8800 T16.
Function enhancement: The board function is enhanced
according to market requirements.
Added the support for the
TN52UXCH and
TN52UXCM boards in the
general OptiX OSN 8800 T32
subrack. The use of the two
new boards increases the OTN
cross-connect capacity of the
subrack from 1.28 Tbit/s to
2.56 Tbit/s and supports
grooming of 640 Gbit/s packet
services.
Function enhancement: The general OptiX OSN 8800
T32 subrack has been improved to support the use of
large-capacity service boards.
Hardware Updates in V100R007C02
Hardware Update
Reason for the Update
Added the support for the
TN11LSQ, TN13LSX,
TN11LOA, TN12LSC,
TN12LOG, TN12TMX,
TN11LTX, and TN12LDX
boards in the OptiX OSN 8800
platform subrack.
Function enhancement: The OptiX OSN 8800 platform
subrack newly supports some OTU boards.
Added the support for the
centralized grooming of
ODU4 signals on the
TN16UXCM board and the
application of 100G tributary
and line boards, and improved
the single-slot cross-connect
capacity of the OptiX OSN
8800 T16 to 100G.
Function enhancement: The subrack capacity is
improved.
Hardware Updates in V100R007C00
Hardware Update
Reason for the Update
