Huawei OptiX OSN 8800 User Manual

OptiX OSN 8800/6800/3800
Hardware Description
4 OptiX OSN 8800 Subrack
Issue 01 (2016-03-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
56
Pin
Signal
Function
negative
3
MAJ_ALMP
Major alarm signal positive
4
RUNP
Power indicating signal
positive
5
RUNN
Power indicating signal
negative
6
MAJ_ALMN
Major alarm signal positive
7
MIN_ALMP
Minor alarm signal positive
8
MIN_ALMN
Minor alarm signal negative
Table 4-33 Pin assignment of the ALMO1/ALMO2 interface
Pin
Signal
Function
1
CRIT_SWITCH_OUTP
Outputs the critical alarm
signal positive
2
CRIT_SWITCH_OUTN
Outputs the critical alarm
signal negative
3
MAJ_SWITCH_OUTP
Outputs the major alarm
signal positive
4
MIN_SWITCH_OUTP
Outputs the minor alarm
signal positive
5
MIN_SWITCH_OUTN
Outputs the minor alarm
signal negative
6
MAJ_SWITCH_OUTN
Outputs the major alarm
signal negative
7
ALM_SWITCH_OUT1P
Alarm signal output 1
positive
8
ALM_SWITCH_OUT1N
Alarm signal output 1
negative
Table 4-34 Pin assignment of the ALMO3/ALMO4 interface
Pin
Signal
Function
1
ALM_SWITCH_OUT2P
Alarm signal output 2
positive
2
ALM_SWITCH_OUT2N
Alarm signal output 2
negative
