Huawei Quidway S3300 Series - Page 19

Model Image
S3328TP-
EI-24S-AC
1 2 4 96 10 12
S3328TP-
EI-24S-DC
1 3 4 96 10 12
S3352TP-
EI-24S
6 9 12115
S3352TP-
EI-48S
7 9 12
11
S3352P-EI/
SI
8 9 12
11
S3328TP-
PWR-EI
5 9 10 12
S3352TP-
PWR-EI
121198
S3328TP-EI-
MC-AC
1 2 4 95 10 12
13
1. Ground screw
2. AC jack 3. DC jack 4. Switch
5. Twenty-four
10/100BASE-T
Ethernet interfaces
6. Twenty-four
100BASE-X Ethernet
interfaces
7. Forty-eight
100BASE-X Ethernet
interfaces
8. Forty-eight
10/100BASE-T
Ethernet interfaces
Quidway S3300 Series Ethernet Switches
Hardware Description 1 Overview of the S3300
Issue 01 (2011-01-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1-7
