Huawei Quidway S3300 Series - 3.2 Fan Module

N
o
.
Air Circulation Model
1
l S3328TP-
PWR-EI
l S3352P-
PWR-EI
2
l S3352P-
SI
l S3352P-
EI
3
l S3328TP-
EI-24S
l S3352P-
EI-24S
l S3352P-
EI-48S
NOTE
On
S3328TP-
EI-24S, air
also flows
into the
chassis from
the left side.
3.2 Fan Module
This section describes the appearance and technical specifications of the S3300 fan module.
Appearance
The S3300 fan module consists of two fans. The fans can be replaced when the device is
operating. Figure 3-1 shows the appearance of the fan module.
