Huawei Quidway S3300 Series - Figure 4-4 Appearance of a Ground Cable; Ground Cables; Table 4-3 Specifications of a Ground Cable

Item Description
Cable type
l 227 IEC 53 (RVV)-300 V/500 V
l Rated voltage: 300 V/500 V
l Standards compliance: 227 IEC 53 (RVV)
Conductor cross-sectional
area
3 x 1.0 mm
2
Fireproof level GB18380.1
4.3 Ground Cables
A ground cable protects the device from lightning strike and electromagnetic interference.
Applications
A ground cable connects the chassis to the ground.
Appearance
Figure 4-4 shows the appearance of a ground cable.
Figure 4-4 Appearance of a ground cable
Specifications
Table 4-3 lists the specifications of a ground cable.
Table 4-3 Specifications of a ground cable
Item
Description
Cable type Power cable
Quidway S3300 Series Ethernet Switches
Hardware Description 4 Cables
