Installation Manual
Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-4
II. LEDs
The S5624P/S5624P-PWR provides one power LED, one RPS LED, one fabric LED,
one module LED, one mode LED, one 7-segment digitron display, four pairs of 1000
Mbps SFP port status LEDs, and 24 pairs of 10/100/1000Base-T port status LEDs on
its front panel.
The S5624F provides one power LED, one RPS LED, one fabric LED, one module LED,
one 7-segment digitron display, 24 pairs of 1000 Mbps SFP port status LEDs, and four
pairs of RJ-45 Combo port status LEDs on its front panel.
Table 1-2 and Table 1-3 describe respectively the LEDs on the S5624P/S5624P-PWR
and S5624F.
Table 1-2 LEDs on the S5624P/S5624P-PWR
LED Mark Status Description
Speed Solid green
The port status LEDs are
showing the speed of each port.
Duplex Solid yellow
The port LEDs are showing the
duplex mode of each port.
Mode LED Mode
PoE
Blinking green
(at 1 Hz)
The port LEDs are showing the
PoE status of each port.
Solid green The switch is started normally.
Blinking green (at 1 Hz)
The system is running power-on
self-test (POST).
Solid red
The system fails the POST, or
there is another fault.
Blinking yellow (at 1 Hz)
Some ports fail the POST and
do not function.
Power LED PWR
OFF The switch is power-off.
Solid green
Both the AC power supply and
the DC input operate normally.
Solid yellow
The AC power supply fails or the
AC input is disconnected, while
the DC input operates normally.
DC LED RPS
OFF DC input is disconnected.
