Installation Manual
Quidway S5600 Series Ethernet Switches Chapter 1
Product Overview
Huawei Technologies Proprietary
1-24
Item S5624P/S5624P-PWR/S5624F S5648P/ S5648P-PWR
Power
module
PSL130-AD: 130 W system output, AC/DC input
PSL480-AD24P: 24-port PoE power module, 180 W system
output + 300 W PoE output (AC input); 180 W system output
+ 370 W PoE output (DC input)
PSL180-AD: 180 W system output, AC/DC input
PSL480-AD48P: 48-port PoE power module, 180 W system
output + 300 W PoE output (AC input); 180 W system output
+ 740 W PoE output (DC input)
Input
voltage
AC input:
Rated voltage: 100 VAC to 240 VAC, 50 Hz or 60Hz
Maximum tolerance:90 VAC to 264 VAC, 50 Hz or 60Hz
DC input:
Rated voltage:
48 VDC to
60 VDC
Maximum tolerance:
36 VDC to
72 VDC
Input
voltage
of PoE
power
module
AC input:
Rated voltage: 100 VAC to 240 VAC, 50 Hz or 60 Hz
Max voltage range: 90 VAC to 264 VAC, 50 Hz or 60 Hz
DC input:
Rated voltage:
53.5 VDC
Max voltage range:
52 VDC to
55 VDC
For S5624P-PWR/S5648P-PWR, use the external RPS
recommended by Huawei-3Com as the DC power input
instead of the
48 VDC power supply generally available in
the equipment room. Any violation may damage the device
due to overvoltage.
Power
supply
RPS
power
Supported
Power consumption
(full load)
S5624P: 170 W
S5648P: 230 W
S5624F: 170 W
S5624P-PWR: 540 W
S5648P-PWR: 600 W
When with PoE power supply:
S5624P-PWR: 540 W (DC input), 560 W (AC input)
S5648P-PWR: 970 W (DC input), 640 W (AC input)
Operating
temperature
0 to 45
o
C
Operating humidity
(non-condensing)
10% to 90%
