Huawei S1720-10GW2P User Manual

No
.
Indic
ator
Name Color Statu
s
Description
5 MO
DE
Mode
switching
button
- - ● When you press this button once,
the service port indicators change
to the speed mode and show the
speed of each service port.
● When you press this button a
second time, the service port
indicators change to the PoE mode
and show the PoE status of each
service port.
● When you press this button a third
time, the service port indicators
restore to the default mode and
show the connection status of each
service port.
If you do not press the MODE button
within 45 seconds, the service port
indicators restore to the default
mode. In this case, the SPEED and PoE
indicators are
o.
6 - Service
port
indicator
Meanings of service port indicators vary in dierent
modes. For details, see Table 5-54.
7 L/A ETH port
indicator
- O The ETH port is not connected.
Green Stead
y on
The ETH port is connected.
Green Blinki
ng
The ETH port is sending or receiving
data.
8 USB USB-
based
deploym
ent
indicator
- O ● No USB ash drive is connected to
the switch.
● The USB port is damaged.
● The indicator is damaged.
● The USB ash drive does not have
any conguration le and cannot
be used for deployment.
● The switch has been upgraded
using the USB
ash drive and is
restarting.
Green Stead
y on
A USB-based deployment has been
completed.
Green Blinki
ng
The system is reading data from a
USB ash drive.
S1700 Managed Series Ethernet Switches
Product Description
5 Hardware Structure
Issue 18 (2020-10-23) Copyright © Huawei Technologies Co., Ltd. 143
