Huawei SmartACU2000D Series User Manual

SmartACU2000D Smart Array Controller
User Manual (with No PID Module)
2 Overview
Issue 01 (2020-02-14)
Copyright © Huawei Technologies Co., Ltd.
10

A maximum of 15 SmartLoggers can be connected to form an optical fiber ring network. Each
SmartLogger can connect to devices such as solar inverters, environmental monitoring instruments
(EMIs), and power meters.

Multiple optical fiber ring networks can be connected to the management system over an Ethernet
switch.

Wireless network: 4G LTE solution
The IP address of the SmartLogger and that of the customer-premises equipment (CPE) must be on the
same network segment.
Figure 2-4 Networking of the SmartACU2000D-D-05CN

Wired network: fiber ring network solution
