Huawei SmartACU2000D Series User Manual

SmartACU2000D Smart Array Controller
User Manual (with No PID Module)
2 Overview
Issue 01 (2020-02-14)
Copyright © Huawei Technologies Co., Ltd.
12
No.
Component
Description
5
Waterproof connector for the DO
signal cable (DO)

Specifications: 5/4 in.

Inner diameter: 20–32 mm
(0.79–1.26 in.)
6
Waterproof connector for the DI
signal cable (DI)

Specifications: 3/4 in.

Inner diameter: 13–18 mm
(0.51–0.71 in.)
7
Waterproof connector for the AI
signal cable (AI)

Specifications: 5/4 in.

Inner diameter: 20–32 mm
(0.79–1.26 in.)
8
USB port (USB)
The USB port is used only for
maintenance (such as upgrade and
data export). Ensure that the USB
cover is tightened when the port is
idle.
9
Waterproof connectors for the
RS485 communications cable or
network cable (RS485/ETH)

Specifications: 3/4 in.

Inner diameter: 13–18 mm
(0.51–0.71 in.)
10
Ventilation valve
-
11
Waterproof connector for the
single-phase AC power cable
(AC INPUT)

Specifications: 3/4 in.

Inner diameter: 13–18 mm
(0.51–0.71 in.)
12
Waterproof connectors for the
three-phase AC power cable
(MBUS01, MBUS02)

Specifications: 1 in.

Inner diameter: 18–25 mm
(0.71–0.98 in.)
13
Waterproof connector for the
optical cable (SFP1)

Specifications: 3/4 in.

Inner diameter: 13–18 mm
(0.51–0.71 in.)
14
Waterproof connector for the
optical cable, network cable, or
4G antenna (SFP2/4G LTE/4G)

Specifications: 3/4 in.

Inner diameter: 13–18 mm
