Figure 5-22 Multi-SUN2000 networking
NO TE
● The RS485 communication distance between the SUN2000 at the end of the
daisy chain and the SmartLogger cannot exceed 1000 meters.
● If multiple SUN2000s need to communicate with one another and are
connected to a PC over the SmartLogger1000, a maximum of three daisy
chains can be congured.
● If multiple SUN2000s need to communicate with one another and are
connected to a PC over the SmartLogger2000, a maximum of six daisy chains
can be congured.
● To ensure the system response speed, it is recommended that the number of
devices on each daisy chain be less than 30.
● Smart Dongle scenario
NO TE
● If the SUN2000 is networked using the SDongleA-03 (4G, Smart Dongle for short), it
cannot be connected to the SmartLogger.
● If the SUN2000-60KTL-M0 version is SUN2000 V300R001C00SPC116 or later, the
RS485_2 port can connect to the DTSU666-H smart power sensor. Due to the power
measurement limit of the DTSU666-H, the current should not exceed 250 A.
● If the Smart Dongle version is SDongle V100R001C00SPC116 or later, the
SUN2000-60KTL-M0 can connect to the DTSU666-H smart power sensor to implement
power scheduling. This document describes only the networking diagrams. For details
about parameter settings, see
Distributed PV Plants Connecting to Huawei Hosting
Cloud User Manual (Inverters + SDongleA) or PV Plants Connecting to SmartPVMS User
Manual (Inverters + SDongleA) .
Figure 5-23 Smart Dongle networking
SUN2000-(50KTL, 60KTL, 65KTL)-M0
