Huawei SUN2000-6KTL-L1 User Manual

6
•
If your Smart Dongle is configured with a SIM card, you do not need to install the SIM card.
The configured SIM card can be used only on the Smart Dongle.
•
If your Smart Dongle is not equipped with a SIM card, prepare a standard SIM card (size: 25
mm x 15 mm) with the capacity greater than or equal to 64 KB.
(Optional) 4G Smart Dongle (4G Communication)
•
For details about how to operate the WLAN-FE Smart Dongle SDongleA-05, see SDongleA-
05 Quick Guide (WLAN-FE)
.
•
For details about how to operate the 4G Smart Dongle SDongleA-03, see SDongleA-03
Quick Guide (4G)
.
•
The quick guide is delivered with the Smart Dongle. You can download them by scanning
the QR code below.
WLAN-FE 4G
• Install the SIM card in the arrow direction.
• When reinstalling the cover of the Smart Dongle, ensure that the buckle springs back in
place (you can hear a click).

Huawei SUN2000-6KTL-L1 Specifications

General

Safety	EN/IEC 62109-1, EN/IEC 62109-2
Efficiency	98.4 %
Product type	-
Maximum power	9000 W
Output current	27.3 A
DC input voltage	350 - 450 V
Number of phases	1
Output frequency	50/60 Hz
Starting voltage	100 V
Output power capacity (max)	6 kVA
Input operation voltage (max)	560 V
Input operation voltage (min)	90 V
Output operation voltage (max)	240 V
Output operation voltage (min)	220 V
Operating temperature (T-T)	-25 - 60 °C
Operating relative humidity (H-H)	0 - 100 %
Wi-Fi	Yes
Product color	White
Power protection features	Over current, Over voltage, Overheating, Reverse polarity, Short circuit
International Protection (IP) code	IP65

Weight and Dimensions

Width	365 mm
Height	156 mm
Weight	12000 g
