Figure 4-2 Parts on the front and rear panels
Table 4-1 Parts description
No.
Parts Description
1 Built-in
microphone
Provides 180-degree sound pickup with an optimal range of six
meters.
2 Lens Shoots video of the local site with 12x optical zoom.
3 MODE button
l When the TE30 is running, press and hold the MODE
button for 10s to reset the TE30 to factory settings. You can
also press this button to make the TE30 sleep or wake up.
l When the TE30 is powering on, press and hold this button
for 3s to enter the mini system.
NOTE
If the endpoint is used in a conference or being upgraded, it will not go
to sleep after you press the MODE button. Instead, a message is
displayed on the remote control UI.
4 Infrared
receiver module
Receives infrared signals from the remote control that comes
with the endpoint.
5 OLED display Displays the IP address, site number, and indications for
startup, upgrade, sleep, and malfunction.
6 Status indicator Shows whether the TE30 is running, sleeping, upgrading, or
malfunctioning.
TE30 Videoconferencing Endpoint
Product Overview
4 Product Structure
Issue 03 (2018-06-30) Copyright © Huawei Technologies Co., Ltd. 11
