HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
4 Display Device and Camera
Issue 02 (2014-03-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
36
The video output formats vary according to port types. Table 4-1, Table 4-2, and Table 4-3
describe the video output ports on the endpoint.
Table 4-1 Capabilities of the TE40's video output ports
Port Name
on the UI
Port
Numbe
r on the
Rear
Panel
Type
Output
Format
Default Settings After
Startup
1 MAIN
OUT
1
HDMI
DVI and HDMI
By default, this port
functions as the main output
port, GUI port, and caption
output port and is used to
display the remote
controlled UI, captions, and
local video. This port can
also be used to switch to
combined pictures.
2 HDMI
OUT
2
HDMI
DVI and HDMI
By default, this port
functions as the auxiliary
output port and is used to
display the local video.
When the Presentation
display function is enabled,
this port is used to display
the local or remote
presentation if a
presentation source is
connected to this port and
display a black screen if no
presentation source is
connected to this port.
3 VGA
OUT
3
VGA
VGA and
YPbPr
By default, this port is used
to display the local video.
Table 4-2 Capabilities of the TE50's video output ports
Port Name
on the UI
Port
Numbe
r on the
Rear
Panel
Type
Output
Format
Default Settings After
Startup
1 MAIN
OUT
1
HDMI
DVI and HDMI
By default, this port
functions as the main output
port, GUI port, and caption
output port and is used to
display the remote
controlled UI, captions, and
