Huawei UA5000 - MUE02 A Sensor Transfer Box; Appearance of the MUE02 A Sensor Transfer Box

Parameter Class Parameter Description
Maintenance mode Front access
Cooling method Forced air cooling, with the built-in fan in the
rectifier module
8.2 MUE02A Sensor Transfer Box
The sensor transfer box provides various sensor ports to connect the external sensors to
monitoring module, collecting signals from the sensors and forwarding the signals to the
monitoring module.
Appearance
Figure 8-5 shows the appearance of the MUE02A sensor transfer box.
Figure 8-5 Appearance of the MUE02A sensor transfer box
Sensor Port
Figure 8-6 and Table 8-8 describe the sensor ports on the MUE02A sensor transfer box.
