Figure 10-17 Relation between the temperature and output current
4 mA
20 mA
-20
80
Current
Temperature
Figure 10-18 shows the relation between the humidity and output current.
Figure 10-18 Relation between the humidity and output current
4 mA
20 mA
0% RH
100% RH
Current
Humidity
