The EPS30-4815AF power system can be configured with two rectifier modules, which are
connected in parallel for output.
Table 6-2 shows the mapping between the quantity of rectifier modules in the EPS30-4815AF
power system and the maximum output current.
Table 6-2 Mapping between the quantity of rectifier modules of the EPS30-4815AF power
system and the maximum output current
Quantity of Rectifier Modules Maximum Output Current
1 15 A
2 30 A
Indicator
Table 6-3 describes the indicators on the rectifier module of the EPS30-4815AF power system.
Table 6-3 Indicators on the rectifier module of the EPS30-4815AF power system
Indicator
Status Description
RUN Steady green The rectifier module functions properly.
Off This indicator is off when the red indicator is
on or the yellow indicator is on (not caused by
output overcurrent).
ALM Steady yellow The ALM indicator of the rectifier module is
valid when PS-off, OTP, and primary
protection are valid, or when overcurrent
occurs.
Blinking yellow The communication of the rectifier module is
interrupted.
Off The rectifier module functions properly.
FAULT Steady red The FAULT indicator of the rectifier module
is valid when PS-enable and Vo-OV are valid,
or when fan fault, no output, or output short
circuit occurs.
Off The rectifier module functions properly.
Table 6-4 describes the indicators on the monitoring module of the EPS30-4815AF power
system.
