Table 3-8 Connections of environment monitoring cables in the F02A cabinet configured with
the J1-type PDU
Cable One End Connects to... The Other End Connects to...
No. Position No. Position
Door status sensor
connecting cable
1 H303ESC JTM1 1 Door status sensors of
the front door and the
rear door
Fan monitoring cable 2 HABA JD1(FAN-
ALM)
2.1 H303ESC JTD1
2.2 H303ESC JTD2
Fan monitoring cable 3 Subtended HABA
JD1(FAN-ALM)
3.1 H303ESC JTD3
3.2 H303ESC JTD4
Monitoring signal
subtending cable
5 HABA JD0 5 Subtended HABA JD0
4 HABA JD2 4 Subtended HABA JD2
ESC monitoring cable 6 HABA JD3 6.1 H303ESC JC1
6.2 H303ESC JC3
Figure 3-5 shows the connections of environment monitoring cables in the F02A cabinet
configured with the J2-type PDU. Table 3-9 describes the cable connections. By referring to
the connection diagram, check whether the connections from each sensor to the H303ESC board
and from the H303ESC board to the control system are correct.
