Monitoring
Parameter
Displayed on the
Host
Device Port Application in the F02A Cabinet
Analog 3 JTA2 Not connected by default, used to add a
user-defined monitoring analog parameter
Analog 4 JTA3 Not connected by default, used to add a
user-defined monitoring analog parameter
Analog 5 JTA4 Not connected by default, used to add a
user-defined monitoring analog parameter
Analog 6 JTA5 Not connected by default, used to add a
user-defined monitoring analog parameter
Analog 7 JTA6 Not connected by default, used to add a
user-defined monitoring analog parameter
Digital 0 JTP1 (MDF) Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 1 JTM1 (door status) Door status sensor
Digital 2 JTD1 Fans of the upper HABA shelf
Digital 3 JTD2 Fans of the upper HABA shelf
Digital 4 JTD3 Fans of the lower HABA shelf
Digital 5 JTD4 Fans of the lower HABA shelf
Digital 6 JTD5 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 7 JTD6 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 8 JTD7 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 9 JTD8 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 10 JTD9 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 11 JTD10 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 12 JTD11 Not connected by default, used to add a
user-defined monitoring digital parameter
Digital 13 JTD12 Not connected by default, used to add a
user-defined monitoring digital parameter
UA5000 Universal Access Unit
Environment Monitoring 3 H303ESC Monitoring Solution
