Monitoring
Parameter
Displayed on
the Host
Device Port Application in the
F02AF Cabinet
(Configured with the C-
Type PDU)
Application in the F02AF
Cabinet (Configured
with the H-Type PDU)
Digital 2 JTD1 Surge protection circuit of
the first DC input of the C-
type PDU
Fans of the HABF shelf
connected to the subtended
HABD shelf
Digital 3 JTD2 Surge protection circuit of
the second DC input of the
C-type PDU
Switch 1 input of the H-type
PDU
Digital 4 JTD3 First output control switch
SW1 of the C-type PDU
Switch 2 input of the H-type
PDU
Digital 5 JTD4 Second output control
switch SW2 of the C-type
PDU
Switch 3 input of the H-type
PDU
Digital 6 JTD5 Third output control switch
SW3 of the C-type PDU
Switch 4 input of the H-type
PDU
Digital 7 JTD6 Monitoring alarm of the C-
type PDU
Input tributary 1 detection of
the H-type PDU
Digital 8 JTD7 Fans of the master HABD
shelf
Input tributary 2 detection of
the H-type PDU
Digital 9 JTD8 Fans of the HABF shelf
connected to the master
HABD shelf
Input tributary 3 detection of
the H-type PDU
Digital 10 JTD9 Fans of the HABD shelf
subtended to the master
HABD shelf
Input tributary 4 detection of
the H-type PDU
Digital 11 JTD10 Fans of the HABF shelf
connected to the subtended
HABD shelf
Fans of the master HABD
shelf
Digital 12 JTD11 Not connected by default,
used to add a user-defined
monitoring digital
parameter.
Fans of the HABF shelf
connected to the master
HABD shelf
Digital 13 JTD12 Not connected by default,
used to add a user-defined
monitoring digital
parameter.
Fans of the HABD shelf
subtended to the master
HABD shelf
Digital 14 Reserved Unavailable Unavailable
Digital 15 Reserved Unavailable Unavailable
Digital 16 Reserved Unavailable Unavailable
