Huawei UPS2000 Series - Technical Specifications

UPS2000-G1-(1 kVA–3 kVA)
User Manual
A Technical Specifications
Issue 05 (2013-07-17)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
29
A Technical Specifications
Item
UPS2000-G1-1
kVA
UPS2000-G1-3
kVA
Input
Rectifier
AC input
Rated input voltage
220 / 230 / 240 V AC
Input voltage range
125–275 V AC (When the input voltage
is 125 V AC, 50% rated load is allowed.
When the voltage ranges from 125 V AC
to 165 V AC, the load power should be
derated.)
Input system
Single-phase, three-wire and PE
Input frequency
50 Hz / 60 Hz (tolerance ±10%)
Input power factor
> 0.95
Bypass
input
Rated input voltage
220 / 230 / 240 V AC
Bypass
synchronized
range
50 Hz / 60 Hz (tolerance ±10%)
Input system
Single-phase, three-wire and PE
Battery
Battery voltage
36 V DC
96 V DC
Number of
batteries
3 (12 V for each)
8 (12 V for each)
Float voltage
40.9 V DC
109 V DC
Equalized charging
voltage
42 V DC
112 V DC
End of discharge
voltage
31.5–33.6 V DC
(automatically
adjusted based on
the load power)
84.0–89.6 V DC
(automatically
adjusted based on
the load power)
Output
Rated power
1 kVA / 0.7 kW
3 kVA / 1 kW
Voltage
220 / 230 / 240 V AC (tolerance ±2%)
