Huawei WA603DE - Basic Configuration; Configure Computer for AP Access

WA603DE & WA653DE
Fat AP Configuration Guide 2 Basic Configuration
Issue 02 (2012-04-19) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd
3
2 Basic Configuration
2.1 Configuring a Computer
1. Perform the following operation according to the operating system:
z
In the Windows XP, choose Start > Control Panel > Network Connections.
z
In the Windows 2000, choose Start > Settings > Network Connections.
2. Right-click Local Connections in the Network Connections window and choose Properties
from the shortcut menu.
Make sure that the properties of local connections, not wireless network connections, are
configured.
3. When the Local Area Connection Properties dialog box is displayed, select TCP/IP and
click Properties. The TCP/IP Properties dialog box is displayed. Record the current
network configuration so that you can restore the network configuration when necessary.
4. Select the Use the following IP addresses option and set the following parameters:
z
IP address: 192.168.0.22 (or 192.168.0.x, where, x indicates a value between 2 and 254.)
z
Subnet mask: 255.255.255.0
You do need to configure the gateway and DNS because the AP is directly connected to the
computer.
5. Click OK to save the settings and close the TCP/IP Properties dialog box. Click OK to close
the LAN Connection Properties dialog box.
The settings take effect immediately.
----End
