B.FILL
Set Bar Fill Mode
This function is used to control how the bar display changes color. The B.COL function is used
to set the colors.
Five different regions in the bar display are defined by
AL1 through AL4:
• > AL1
• AL1 to AL2
• AL2 to AL3
• AL3 to AL4
• < AL4
The color of the bar in each of these regions may be defined by the B.COL function.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
The display will show the current Bar Fill setting. Options for this setting and
the order they appear are shown below.
Pressing the INCREASE or DECREASE pushbutton will cycle through the
options shown below.
TriColor mode. The bar is one solid color that changes for each of
the regions described above. Typically, the bar is set for green
(safe) for
AL2 to AL3, yellow (caution) for AL1 to AL2 or AL3 to
AL4 and red (danger) for > AL1 or < AL4.
TRI
BAMD
Press
ENTER/SAVE
Press ENTER/SAVE to store the new setting.
Color banding mode. The bar has a specific color in each of 5
different regions on the display. Typically, the bar is set for green
(safe) for
AL2 to AL3, yellow (caution) for AL1 to AL2 or AL3 to
AL4 and red (danger) for > AL1 or < AL4.
Note: When in Variation or Deviation mode (see Barform), 6
regions may be present due to the Zero point.
Note: These regions assume that AL1 is
the highest and
AL4 the lowest
alarm setpoints. Setpoints may be
arranged in any order, however.
