23
HI.COL
Set Hi Setpoint Color
LO.COL
Set Lo Setpoint Color
This function is active only if B.FILL was set to TRI (TriColor). This function is used
to set the default color for the
HI setpoints. One segment of the bar display will be illumi-
nated in this color at the alarm setpoint values.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current HI setpoint color setting.
Pressing INCREASE or DECREASE will increment or decrement the LED
brightness setting one step. The display will change to show the effect of the
new setting.
To save the new
HI setpoint color setting, press the ENTER/SAVE pushbutton.
This function is active only if B.FILL was set to TRI (TriColor). This function is used
to set the default color for the
LO setpoints. One segment of the bar display will be illumi-
nated in this color at the alarm setpoint values.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The bar display will change to a solid bar with the current LO setpoint color
setting.
Pressing the INCREASE or DECREASE pushbutton will cycle through the
colors Yellow, Green and Red. The bar display color will change to show the
current choice.
Press ENTER/SAVE to store the new setting.
Note: The
HI setpoint color will always differ from the bar color and LO setpoint
color.
Note: The
LO setpoint color will always differ from the bar color and HI setpoint
color.
