Hughes weschler instruments BarGraph TriColor Series User Manual

24
BRIGH
LED Brightness
B.FLSH
Bar Flash Enable
This function controls LED brightness. Sixteen settings are available: 1 to 16. 1 is the
dimmest setting while
16 is the brightest. The factory default setting is 12.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current LED brightness setting.
Pressing INCREASE or DECREASE will increment or decrement the LED
brightness setting one step. The display brightness will change to show the
effect of the new setting.
To save the new LED brightness, press the ENTER/SAVE pushbutton.
During an overrange/underrange condition, the Bar Display may be set to flash. This function
is used to enable or disable the flashing of the Bar Display.
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show OM or 0FF to indicate the current state.
Pressing INCREASE sets flashing
OM, pressing DECREASE sets flashing
0FF.
To save the new Bar Flash Enable setting, press the ENTER/SAVE pushbutton.
