Hughes weschler instruments BarGraph TriColor Series User Manual

29
SGMAL
Signal Source
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current signal source.
Pressing the INCREASE or DECREASE pushbutton will set the signal source
to
DC-AC or ASCII respectively.
To save the new signal source setting, press the ENTER/SAVE pushbutton.
This function defines which signal source will be displayed. There are two choices:
• DC-AC - the signal source is an AC or DC signal input (analog)
• ASCII - the display value is sent as ASCII characters from a serial port (digital)
B.SIZE
Set Buffer Size
Press
ENTER/SAVE
Press
INCREASE
DECREASE
Press
ENTER/SAVE
The display will show the current buffer size.
Pressing the INCREASE or DECREASE pushbutton will increase or decrease
the buffer size. The minimum is 1; the maximum is 20.
Press ENTER/SAVE to store the new setting.
This function sets the number of readings averaged before the display is updated. The number
of readings is the size of the buffer.
