Hunter DSP9100 - Table of Contents

Contents
Error Codes.........................................................................................................1
Diagnostic Mode.................................................................................................2
Special Setup Items............................................................................................3
Resetting All Setup Items to Default.................................................................3
Motor Test Mode.................................................................................................3
Auto-Spin Mode ..................................................................................................3
Motor PID Setting Mode .....................................................................................4
Switch Test..........................................................................................................4
Display Test.........................................................................................................4
Resetting Setup Items to Default.......................................................................4
Configuration Jumpers ......................................................................................5
Identifying Balancer Model and Software Version...........................................6
Changing Software (Replacing EPROM)...........................................................6
Skip Inner Arm Calibration and Calibrate Outer Arm ......................................6
Calibration Procedures ......................................................................................7
Quick Cal Check................................................................................................................ 7
Balancer Calibration......................................................................................................... 7
Inner Dataset® Arm (Calibration Tool, 221-672-1, Required) ....................................... 9
Outer Dataset® Arm (Calibration Tool, 221-672-1, Required) ....................................11
Enabling/Disabling Inflation Station and Changing Units .......................................... 11
Inflation Station Calibration...........................................................................................11
Calibration Results...........................................................................................12
Status bits for the Balancer Spin Calibration ..............................................................13
Status bits for the Inner Dataset® Arm......................................................................... 14
Status bits for the Outer Dataset® Arm........................................................................ 15
DSP9600/9100 Service ManualDSP9600/9100 BalancerDSP9600/9100 Balancer Contents • i
