SPECIFICATIONS
Dimensions: 3 ½"(89 mm) diameter, 2 ½"(64 mm) high
Sensor inputs: One
Power source: One nine-volt alkaline battery (use two for extended
battery life). Activates DC latching solenoids operating 9-11VDC
(Hunter PN 458200).
Operating temperature: 0ºF to 140ºF
(-17ºC to 60ºC)
Approvals:
IP68
CE
FCC
C-Tick
TROUBLESHOOTING GUIDE
Problem Causes Solutions
There is no display.
Display is o.
Battery is dead.
Press any button for one second.
Replace the battery.
Display indicates watering but
none is occurring.
No water pressure.
Faulty solenoid.
Incompatible solenoid.
Turn on main system supply.
Replace solenoid.
Must use Hunter DC latching solenoid (P/N 458200) or
other compatible DC latching solenoid.
Automatic irrigation does not
start at start time.
Controller in System O mode.
AM/PM/time of day not set correctly.
AM/PM/start time not set correctly.
Verify that controller is programmed for
automatic watering.
Correct AM/PM/time of day.
Correct AM/PM/start time.
Rain sensor does not suspend
watering.
Rain sensor defective or miswired. Verify proper operation of the rain sensor and wire
connections (see page 11).
Controller waters more than one
time.
The program has more than one start time
assigned to it. Each program has up to four
start times.
Eliminate program start times as needed.
15
