ENG
6. All 4 numbers are shown with the two numbers on the left
ashing, representing the hour. Use the or buttons to
change the hour. Press the button to proceed to setting
the minutes.
7. All 4 numbers are shown with the two numbers on the right
ashing, representing the minutes. Use the
or buttons
to change the minutes. Pressing the button will advance
to the year setting at step #2.
8. Press the
button to proceed to the next programming
function or allow controller to return to idle mode.
Setting Watering Start Times
1. Press the
button until the icon is displayed.
2. The start time will be displayed ashing, along with the
program letter (A, B, or C) and the start time number (1, 2, 3,
or 4) in the upper left of the display. Up to 4 different start
times can be set for each program.
3. Use the or buttons to change the start time for the
program that is displayed. Each press of the button will change
the start time in 15 minute increments.
4. Press the button to add an additional start time to the
program displayed. The start time number is shown in the
upper left corner of the display.
5. Press the
button to add start times to a different program.
6. Press the
button to proceed to the next programming
function or allow controller to return to idle mode.
NOTE: After programming the run time for the
last station press the button to display the
total run time for the program.
Setting the Run Times
1. Press the
button until the icon is displayed.
2. The run time will be displayed ashing. Also shown is the
program letter (A, B, or C) and the active station # on the lower
left side of the display. Press the
or button to change
the station run time from 1 minute to 6 hours.
3. Press the
button to advance to the next station.
4. Press the
button to add a run time to another program.
5. Press the
button to proceed to the next programming
function or allow controller to return to idle mode.
PROGRAMMING (CONTINUED)
8
