Husqvarna Automower User Manual

50 - English
6. MENU FUNCTIONS
Exit angles (3-1)
Normally Automower leaves the charging station in a
direction within the exit sector 90°-270°, where 90° is
called the Start angle and 270° is called the End
angle. By setting the start and end angles, you can
set the direction in which Automower is to leave the
charging station.
The mower can be set for up to two exit sectors. If the
charging station is placed in a passage it may be
necessary to have two exit sectors, e.g. 70° - 110°
and 250° - 290°.
When you use two exit sectors, you also need to state
how often the mower should leave the charging
station in sector 1. This is done using the Proportion
first function by stating a percentage. For example,
the percentage 75 % means the mower will leave the
charging station in sector 1, 75 % of the time and in
sector 2, 25 % of the time.
• Reversing distance (3-1-1)
Specify the number of centimeters you want
Automower to reverse before it turns to drive out
of the charging station.
The default reversing distance is 60 cm (24").
• Start angle 1 (3-1-2)
Specify in degrees where you want the
sector/sector 1 to start.
• End angle 1 (3-1-3)
Specify in degrees where you want the
sector/sector 1 to end.
• Start angle 2 (3-1-4)
Specify in degrees where you want the sector 2
to start.
• End angle 2 (3-1-5)
Specify in degrees where you want the sector 2 to
end.
3012-817
3012-841
Sector 1
Sector 2
3-1
3-1-
Reversing dist.
Start angle 1
End angle 1
Start angle 2
End angle 2
Proportion first
Exit angles
Follow loop
Garden shape
Advanced
