1-8 INSTALLATION
P/N 3110586_A U.S. & Canada 1-800-922-1919 • Mexico 01 800-890-2900 • www.hussmann.com
Remove screws from corner high side (RH), only the ones attached to wood panel front.
4. Carefully pull the wood panel front to the le.
5. Remove screws on the condensing unit bae. Remove the bae to access the condensing unit.
Pull Wood Front Panel
to the Left
Condensing Unit
Condensing Unit Baffle
Elecrical Control Box
Pull Wood Front Panel
to the Left
Condensing Unit
Condensing Unit Baffle
Electrical Control Box
