Hussmann SMG8B - Sensor Location and Control Adjustments

3-6 startup / opEratIon
P/N 3018126_E U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
P/N 3018126_E 3-7
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
SMG8B & SSG8B
Safe-NET Location on Rear of Case
(Rear Panel Removed)
Dixell Control Sensor Location
Sensor is located
under the gravity
coil for SMG8B
Sensor is located
under the coil at
the rear of the
case for SSG8B
Dixell XR75 Controller
