1. The Dixell XR75 Controller controls
refrigeration temperature. This is factory
installed in the control panel. Measure
discharge air temperatures at the center of the
honeycomb.
For low temperature models, defrosts are
time initiated and temperature terminated.
The defrost setting is factory set as shown. To
ensure a thorough defrost, the defrost must
be terminated by the temperature termination
setting — not by time. For medium
temperature models, defrost is time initiated
and temperature terminated.
START UP
Follow the Dixell XR75 start up procedures as
detailed on Page 3-1 of this manual.
Each self contained merchandiser has its own
evaporator coil and a pre-set thermostatic
expansion valve (TEV). The TEV has been
factory set at design conditions to provide the
recommended performance.
CONTROLS and ADJUSTMENTS
Refrigeration Controls Defrost Controls
Model
SMG
Product
Application
Discharge Air
Temperature
Cut Out
Defrost
Frequency
(per day)
Type of
Defrost
Failsafe
Time
(Minutes)
Off Time
19° F
90
1
Medium Temp.
(Dairy, Deli,
Produce)
SSG
Off Time
90
1
Medium Temp.
(Dairy, Deli)
17° F
Discharge Air
Temperature
Cut In
25° F
Discharge Air
Temperature
24° F
21° F
26° F
