SELF-SERVICE DELI REVISION DATE 04/07/21
HUSSMANN – TY(A)3ECRC-3-S SELF CONTAINED
REFRIGERATION DATA:
CASE LENGTHS CASE USAGE
CONVENTIONAL
CAPACITY ***
(BTU/HR/FT)
AVERAGE DISCHARGE
AIR** (°F) (SEE
SETPOINTS BELOW)
VELOCITY
(FT/MIN)
4.5E, 5.5E DELI 2100 28~32 125~175
**FRONT DISCHARGE AIR MEASURED INSIDE AIR CURTAIN HONEYCOMB
***REFRIGERATION NOTES:
1) CAPACITY FOR REFERENCE ONLY
2) DEFROST FOR IS BASED ON TERMINATION TEMP, W HICH UNDER
NORMAL CIRCUMSTANCES, IS SHORTER THAN FAILSAFE TIME.
REFRIGERATION DATA CONTINUED:
END PANEL WIDTH KEY
# OF END
PNLS
END PNL
WIDTH
(IN.)
TOTAL ADDED
LENGTH (IN.)
1 1.125
1.125
2 1.125 2.25
ELEC. THERMOSTAT / AIR
SENSOR SETTINGS
DEFROST
TYPE
TIME
(MIN)
DEFROST
FREQUENCY
(#/DAY)
TERM.
TEMP
(°F) COI
L
ONLY
DRIP
TIME
DEFROST
WATER
(LBS/DAY/FT)
USAGE
SET
POINT
(°F)
DIFFER-
ENTIAL
(°F)
4.5E 23 8 OFF TIME 40
12
46 N/A
3.8
5.5E 22 8 OFF TIME 40
12
48 N/A
3.8
ELECTRICAL DATA:
STANDARD FANS, HEATERS, LED LIGHTS (115 VOLT)
CASE LENGTH
EVAPORATOR FANS
CANOPY LIGHTS
LED
OPTIONAL LED
SHELF LIGHTS
MAX. LED LOAD
(W/ ALL OPTIONS)
ANTI-SWEAT
HEATERS
CONVENIENCE OUTLETS
(OPTIONAL)
# OF
EVAP
FANS
BLADE
DIA. (IN.)
BLADE
PITCH (°)
AMPS WATTS AMPS WATTS AMPS WATTS AMPS WATTS AMPS WATTS
#
OUTLETS
VOLTS AMPS
4.5E 4 8 SEE
GRAPHIC
1.2 32 0.6 73 0.3 35 0.9 108 0.7 80 1 115 15
5.5E 6 8 1.8 48 0.3 34 0.4 46 0.7 79 0.7 80 1 115 15
CONDENSING UNIT AND EVAPORATIVE PANS
CASE LENGTH
CONDENSING UNIT
EVAPORATIVE PAN
NEMA
PLUG
EST. REFG.
CHRG.
NOM. HP REFRIG. Hz/Ph Volts RLA VOLTS AMPS WATTS KG OZ
4.5E 1 1/4
R-448A
60 / 1 208 9.3 208 7.2 1500 L14-30P 1.6 58.0
5.5E 1 3/4 60 / 1 208 12.6 208 7.2 1500 L14-30P 2.0 70.5
OPTIONAL HIGH OUTPUT LED LIGHTS (115 VOLT)
CASE LENGTH
CANOPY
LIGHTS
H.O. LED
OPTIONAL SHELF
MAX. H.O. LED
LOAD
AMPS WATTS AMPS WATTS AMPS WATTS
4.5E N/A N/A N/A N/A N/A N/A
5.5E N/A N/A N/A N/A N/A N/A
