User Manual
HV Diagnostics Page 10 Rev 9.0
3 General Description
3.1 Technical Specifications
Characteristic HVA34
1
Input Supply Voltage 110-240V; 50/60 Hz ; ±10%
Input Supply Power 400VA
Output Voltage
[Max.]
VLF Sinewave: 24kV rms , 34kV Peak
VLF Squarewave: 34kV
DC: ±34 kV
Output Current
[Max.]
Sinewave: 10mA rms
Squarewave / DC [+/-]: 15mA
Output Frequency 0.01 Hz -0.1Hz in 0.01 Hz increments
Sheath Test max. Test Voltage: 10 kV, Duration: 1 min – 15 min
Trip Current: 0.1 mA – 5.0 mA
Sheath Fault Location Mode
2
max. Test Voltage: 10 kV, Duration: 1 min – 60 min
Pulse/Period: 1:3 / 4 s, 1:5 / 4 s, 1:5 / 6 s, 1:9 / 6 s
Frequency optimization Yes
Output Load Capacity At Full rated voltage at 0.1Hz: 0.5µF
Max. at reduced frequency and or reduced voltages: 12µF
Metering Current Resolution: 1µA, Accuracy: ±1%
Voltage: Resolution: 0.1kV, Accuracy: ±1%
Capacitance: 0.1nF - 20µF
Resistance: 0.1 MΩ -20GΩ
Output Duty Continuous! No thermal limitation for operating time.
Test Modes Manual
Automatic
Output Modes
[Load independent,
symmetrical]
VLF AC Sinewave
VLF AC Squarewave
DC [+ or – polarity]
Vacuum Bottle Testing
Sheath
Sheath Fault Location Mode
Arc Management Modes Fault Conditioning Mode: Burn on Arc
Fault Trip Mode: Trip Out on Arc
Computer Interface RS232 and USB Flash Memory Module
Record Storage Built in Memory: up to 50 reports , 40 Test sequences
USB Memory Flash drive: Unlimited
PC Software [included] HVA Control Center for Windows XP / 7 / Vista
Weight
43lbs / 19.5kg
Dimensions
[excluding handles]
17” x 14” x 10” / 430mm x 360mm x 250mm
Environment Storage Temperature: -25°C to 70°C (-13°F to 158°F)
Operation Temperature: -5°C to 45°C (23°F to 113°F)
Humidity: 5-85% non-condensing
1
Technical Specifications are subject to change. HV Diagnostics reserves the right to modify values in accordance with future
HVA development.
2
in combination with locator set (not in scope of supply)
