6.3 Automatic Test Mode
This HVA test mode allows automatic testing of a DUT according to a
specific sequence in order to satisfy specific requirements (e.g. IEEE,
IEC standards). The test sequence can be configured, modified and
saved at any time before testing.
Configuring Auto Test. Sequence- Detailed Steps
NOTICE
No Automatic Test Sequence programmable for Sheath/Jacket Test and
Sheath Fault Location.
Already programmed in Manual Mode!
Main Menu
USB
Use Last Test Seq.?
3.0kV Maint. C. HYBR (T)
(T)
Start a New Test
Manual Mode
Reports & Setup
13.3.2009 10:23
Reports &Setup
Reports & Setup
View Reports (50)
Store Rep. to USB
Edit Auto Test Seq.
Instrument Settings
Display Contrast 4
Service
MAIN
Edit or New?
Edit Auto Test Seq.
3.0kV Maint. C.
HYBR (T)
BACK SELECT
EDIT DEL NEW
Edit Auto Test Seq
.
3.0kV Maint. C. HYBR (T)
BACK SELECT EDIT DEL
NEW
Set Sequence
Save Sequence
Edit Auto Test Seq.
3.0 kV Cable HYBR
Maintenance / Sine 0.1Hz
Test Voltage: 1.0kVrms
Duration 15min
Trip out on Arc
Finished
Save or Cancel
CANCEL PREV
SAVE
New Auto Test Seq.
1.0 kV Cable XPLE
Maintenance / Sine 0.1Hz
Test Voltage: 1.0kVrms
Duration 15min
Trip out on Arc
Finished
Save or Cancel
CANCEL PREV
SAVE
HVA guides user through series of questions
• DUT Type
• Voltage Rating
• (Cable) Insulation
• Test Purpose
• Waveform
• Frequency
• Voltage Steps
• Test Voltage (for each step)
• Duration (for each step)
• Arc Management Mode
