3.3 Materials
Shipment Content
Items included upon delivery of the HVA are listed below. The * marking
specifies items that are country specific. For inquiries, please contact HV
Diagnostics.
Part. No. Item Description Qty
734 001 HVA34 1
700 501
HVA 34 HV Test Lead + Alligator Clamps
50kV / 4m
1
700 505 Grounding Cable Transparent
6mm
2
(10 AWG) / 4m (13ft); with 400A alligator
clamp
1
Grounding Cable Green 1
700 048 HV External Remote Interlock Adapter 1
700 907
Power On Key
Spare key for Key switch (7)
1
700 902 Cable RS232 Serial Communication Cable 1
Mains / AC Power Cable* 1*
700 909
USB-RS232 Adapter
FTDI USB Adapter UC232R-10
1
700 199 USB Flash Drive HV Diagnostics 1
HVA Control Center Software 1
HVA 34 Operation Manual 1
