3.2 Design Features
To assure that the workplace is safe and that operators can fulfil their
responsibilities with ease, the HVA provides the following features.
Feature Purpose / Application Advantage
Optimized Frequency
Selection /
Automatic load
measurement
•
To test capacitive loads
• No instrument restart necessary
•
Facilitates testing
• Limits number of
connections to the DUT
Fully Automatic Test
Sequences
•
To test according to IEEE or other
standards
•
Facilitates complex testing
• Facilitates test repetition
Real Time Display
•
To indicate instantaneous output
voltage display.
•
Facilitates testing
Load independent
output
•
To indicate true symmetrical
sinusoidal and square wave
waveforms output
•
Facilitates testing
Built in Memory
•
To save test sequences
• To save test reports
•
Facilitates test repetition
• Facilitates documentation
Arc Management
•
To provide short-circuit protection
• To allow for fault conditioning
•
Limits test interruptions
commonly encountered
when using conventional HV
test instruments that
immediately trip on arc
detection.
Automatic load
measurement
•
To limit connections to the DUT
•
Facilitates testing
Intelligent Design
•
Minimum moving parts and no
need for lubrication
•
Reduces maintenance
• Improves instrument
durability and reliability
Instrument Lock-
Key switch (7)
•
To prevent against unauthorized
use
•
Improves safety
Local and remote
emergency off switches
•
To shut down operations in an
emergency situation
•
Improves safety
Fully integrated
discharge and transient
circuit
•
To ground the DUT after testing
• To protect the unit from transient
over voltages
•
Improves safety
• Protects instrument
Initial load clearance
test at reduced voltages
•
To check automatically for shorts
or grounds, during load
measurement, before test
initiation
•
Improves safety
Return Voltage
Indication
•
To monitor external high voltage
greater than 100V (AC)
•
Improves safety
Discharge Status
Indication
•
To indicate when DUT is not fully
discharged.
LED Red (3) lights when residual
voltage greater than 100V
•
Improves safety during
normal disconnection
procedures
