5 Design and Construction
5.1 Control Elements
HVA control and connection components are located on 3 panels
Panel- Orientation
Orientation Description
Front
• Test controls and emergency shutdown
• HV status information
Left Side
• Cable and power source connections
• External connections
• Air Vent
Right Side
• RS232 port / USB Flash Adapter
• Air Vent
Right Side Panel Left Side Panel
Front Panel
