User Manual
Rev 9.0 Page 31 HV Diagnostics
Steps AS 1-AS 15 describe how to configure a test sequence.
Step Procedure (Configure Automatic Sequence) Example
AS 1:
EDIT or NEW?
The “Edit Auto Test Seq”. Menu displays the
sequences already stored in memory.
• To modify an existing program, highlight the
corresponding program from the list and select
the “EDIT” option, on the bottom of the screen
• To create a new program, select the “NEW”
option, on the bottom of the screen
AS 2:
DUT
Select one of the following DUT types:
Cable
• Motor
• Generator
• Transformer
Switchgear
• Other
• Vacuum Bottle
AS 3:
Voltage Rating
Specify the voltage rating of the DUT.
This is a characteristic of the DUT and does
NOT refer to the test voltage!
To increase / decrease the voltage rating, rotate
navigation knob (5).
To accept value, push in knob.
• Min. rating = 0.1 kV, Max. rating = 50.0 kV
AS 4:
(Cables Only)
Insulation
Select one of the following cable insulation types:
XLPE
• PILC
• EPR
• PE
PVC
• HYBRID
(combination of types)
• OTH. (other)
AS 5:
Test Purpose
Select aim of test from one the following:
• Acceptance
• Maintenance
• Diagnostic
AS 6:
Waveform
Select one of the following output modes:
• Sine wave
• Square wave
• DC+
• DC-
• Vacuum Bottle Test
AS 7:
Frequency
(Sinewave or
Squarewave only)
Set the frequency to as close to 0.1Hz as possible.
• 0.1 Hz/Auto: Recommended setting that
automatically maintains the frequency as close
to 0.1 Hz as possible
• Permitted values: 0.01 - 0.1 Hz in 0.01 Hz
increments
What is the
Device under Test?
Cable
Cable
What is the
Voltage Rating of DUT?
1.0kV
1.0kV Cable
What type of
Insulation?
XLPE
1.0kV Cable XPLE
Test Function?
Maintenance
1.0kV Cable XPLE
Maintenance
Waveform for Test?
Sine
1.0kV Cable XPLE
Maintenance / Sine
Frequency for Test?
0.1Hz/ Auto
To Next Page
