Step Procedure (Configure Automatic Sequence) Example
AS 8:
Voltage Steps
Specify the number of voltage steps to be applied
to the DUT.
• Min. voltage levels: 1 Step
• Max. voltage levels: 4 Steps
AS 9:
Test Voltage
Specify test voltage for each step:
• Min. voltage = 0.1 kV
• Max. voltage = 24.0 kV rms (for VLF)
= 34.0 kV (for DC)
For multiple voltage steps:
HVA automatically advances to next step.
Values are displayed in a table.
AS 10:
Duration
Specify test duration for each step:
• Min. test duration / step = 1 minute
• Max. test duration / step = 120 minutes
For multiple voltage steps:
HVA automatically advances to next step.
Values are displayed in a table.
AS 11:
Arc Management
Mode
Select one of the following arc management
modes:
• Trip out on Arc
• Burn on Arc
AS 12
(Vacuum Bottle
Only)
Trip Current
Set the test “Trip Current”:
• Min. = 200 µA,
• Max. = 1000 µA
AS 13
(Vacuum Bottle
Only)
Rise Rate
Set the test “Rise” rate:
• Min. = 0.5 kV/s
• Max. = 5.0 kV/s
AS 14:
Save Sequence
Test sequence setup is complete.
• To save the program select “SAVE”.
The program will be stored under a name referring
to its test parameters.(To modify name, see AS15)
The sequence is found in the “Edit Auto Test Seq.”
Menu display. See Step AS 1.
New Auto Test Seq.
0.1kV Cable XPLE
Maintenance/Sine0.1Hz
How many Steps?
1 Step
CANCEL PREV
NE
XT
New Auto Test Seq.
1.0 Cable XPLE
Maintenance/Sine0.1Hz
Test Voltage: 1.0kVrms
Step 1
Test Voltage
1.0kVrms
CANCEL PREV
NE
XT
New Auto Test Seq.
60.0 kV Cable XPLE
Maintenance/Sine0.1Hz
Test Voltage: 1.0kVrms
Step 1
Duration
15 min
CANCEL PREV
NE
XT
New Auto Test Seq.
1.0kV Cable XPLE
Maintenance/Sine0.1Hz
Test Voltage: 1.0kVrms
Duration: 15 min
Current Limit?
Trip out on Arc
CANCEL PREV
NE
XT
New Auto Test Seq.
60.0kV Vacuum Bottle
Maintenance
Test Voltage 1.0kV
Duration: 1min 0sec
Trip Current?
200µA
CANCEL PREV
NE
XT
New Auto Test Seq.
60.0kV Vacuum Bottle
Maintenance
Test Voltage 1.0kV
Duration: 1min 0sec
Rise Rate?
0.5kV/ s
CANCEL PREV
NE
XT
New Auto Test Seq.
1.0 kV Cable XPLE
Maintenance/Sine0.1Hz
Test Voltage: 1.0kVrms
Duration: 15 min
Trip out on Arc
Finished
Save or Cancel
CANCEL PREV
SAVE
